Making thumbnails load reasonably quickly is surprisingly complex for such a common problem. With Shadow Buckets, Tigris can take over much of the heavy lifting for you. Don't worry about who is reading your sandwich review blog around the world - we'll make sure your thumbnails are right there when you need them, from Chicago to Singapore.
Doing this the old way, you'd need:
- A URL format to define the expected operation and the source file to apply them to
- A storage solution to keep source files around
- A server running accepting requests, fetching sources and applying operations
- A cache to retain results and serve them for futher requests to the same URL
- Distribute caches to locations close to users for optimal latency serving them
In a common setup a CDN would be placed in front of a thumbnailing server, which then further needs access to some storage holding source files. More recently, developers tend to implement those thumbnailing servers as serverless components.
There's a bunch of existing pieces, which could can be combined to fill those various roles, but in this blog post we'll explore using Shadow Buckets to simplify that setup.
The Setup
Let's see how Shadow Buckets can make your life easier! With Shadow Buckets enabled Tigris will fetch files, which do not exist in a bucket, from another S3-compatible source, caching them for later requests. By storing thumbnails in a Tigris bucket we get access to the CDN features of Tigris, which will not just cache thumbnails, but also distribute them to regions close to users for fast access to those thumbnails.
Tigris buckets will also store source files. While end users might not directly access source files they still benefit from the same distribution across regions.
If a nearby region already has the source file then generating a thumbnail can happen in a close, if not the same, region as well – especially if the service to generate the thumbnail is also hosted on Fly like Tigris.
Where users can upload sources it's also likely they'd trigger the generation of thumbnails on those sources, which would all happen close to their location, reducing latency in many of the steps involved.
Using Tigris for both sources and thumbnails also means there's only a single API to deal with. Be it uploading sources or expiring thumbnails on overwrites – the S3 API would handle both.
"S3-compatible" Thumbnail Generation
Given the Shadow Bucket feature is primarily meant to reach into another S3 based storage the target for it needs to be somewhat "S3-compatible". Luckily that's not too difficult, given the feature actually uses only a small subset of that API to work.
ListObject is currently used to confirm Tigris can reach an endpoint
configured as Shadow Bucket and at least to a degree conforms to the expectation
of being S3-compatible. The thumbnailing service can return a static dummy
response and that should make the configuration succeed.
GetObject is the more interesting one, given that's the API call used to
retrive any non-existant files. That one is not that special though given it's
for the most part a plain http request for a file – but with some additional S3
specific headers, which you can ignore for this use-case :) When accessed, these
routes will use the provided path to get details about the requested thumbnail
and return it once generated.
The Implementation
Ready to see how this magic works in practice? Don't worry, we'll walk you through it step by step!
To test this out I deployed an Elixir service using Phoenix on Fly together with a fresh Tigris bucket. I also enabled the Shadow Bucket feature pointing it towards that Elixir service.
For rendering the homepage the service uses a function component, which takes in
a source and various attributes around thumbnailing like size:
<.image src="example.jpg" size={{640, 0}} />
The function component then turns those attributes into a URL pointing to the
related Tigris bucket, which the function component continues to use as the
source on the rendered <img /> tag.
For this implementation I chose the format defined by Thumbor. Thumbor is a python tool for thumbnail generation - for which I happened to have a URL builder/parser around from a project I maintain.
path =
%ThumborPath{
source: assigns.src,
size: assigns.size,
filters: ["quality(85)"]
}
|> ThumborPath.build(ShadeScale.thumbor_secret())
Path.join(ShadeScale.thumbor_host(), path)
The resulting URL would look something like this:
https://shade-scale.fly.storage.tigris.dev
/fqagdEceJb3wnaQs_2ZFPVxWz9s=
/640x0
/filters:quality(85)
/example.jpg
A user visiting the homepage would then request that file from the host being the Tigris bucket.
If the file exists in the bucket Tigris would serve it directly - so 🎉.
If not a GetObject would be made to the Elixir service requesting the file
using that thumbor-formatted path. Given there's a few steps to handling those
requests the Phoenix router forwards them to a plug, which takes care of those
steps one by one. Plug.Builder does a great job composing individual plugs per
step to one module, which also implements the plug interface.
The first step is a check that the path is a valid one, which has not been
tampered with and if so stores the parsed data on the conn.assigns:
defp check_hmac(conn, _) do
path = conn.path_info |> Path.join() |> URI.decode()
if ThumborPath.valid?(path, conn.assigns.secret) do
assign(conn, :thumbor_path, ThumborPath.parse(path))
else
conn
|> send_resp(:forbidden, "")
|> halt()
end
end
In the next step the system fetches the source from the Tigris bucket:
defp fetch_from_source(conn, _) do
[bucket | _] = String.split(conn.host, ".")
%ThumborPath{source: path} = conn.assigns.thumbor_path
req = Req.new() |> ReqS3.attach()
case Req.get(req, url: "s3://#{bucket_to_query}/#{path}", retry: false) do
{:ok, %{status: 200, body: image}} when is_binary(image) ->
assign(conn, :source, image)
{:ok, %{status: status}} when status in [200, 404] ->
conn |> send_resp(404, "") |> halt()
{:ok, %{status: 500, body: body}} ->
conn |> send_resp(500, body) |> halt()
end
end
If both of those steps complete successfully the service applies the operations
provided on the URL. The path segments are translated to parameters and calls to
the :image library of elixir, which brings libvips image transformation
capabilities into elixir.
That code is a little too much for a blog posts, but it boils down to something similar to this:
defp apply_transformations(conn, _) do
%ThumborPath{} = thumbor_path = conn.assigns.thumbor_path
{:ok, image} = Image.from_binary(conn.assigns.source)
{:ok, image} = Image.thumbnail(image, size(thumbor_path), opts(thumbor_path))
{:ok, bin} = Image.write(image, :memory, opts(thumbor_path))
conn
|> put_resp_content_type(MIME.from_path(thumbor_path.source), nil)
|> put_resp_header("content-length", bin |> byte_size() |> Integer.to_string())
|> send_resp(200, bin)
end
The response is then forwarded to the initial requesting user by Tigris and caches it for further requests of that thumbnail – again 🎉.
Considerations
This experiment turned out to work quite well for the goal of making it work. That however doesn't mean it's meant to go into a production system as is though.
One concern with image processing is always CPU (or even GPU) resources. Having an app server also do the thumbnailing is in my opinion a great setup to get started. It runs locally with your app server and by skipping the caching - make the app server be the host for images - you get quite a bit of "full stack" capabilities just using your app.
But that setup isn't common for reasons. Once you need to generate many thumbnails that takes quite a bit of resources away from an app server. For Elixir and Phoenix specifically however I might eventually look at FLAME to scale that service. By pushing the thumbnail generation portion to additional nodes the resource requirements might be fine in production, while retaining the benefits of running everything "inline" for local development.
The other concern to talk about would be granular caching durations. Using the Shadow Bucket feature means the system will cache thumbnails for as long as their files stay on the bucket. CDN services commonly deal with cache headers provided by the downstream endpoint and expire cached files according to those headers. We might also explore a better answer to that concern more closely at a later time. For now the implementation makes use of the common "immutable" approach of "never delete a cached thumbnail unless asked for".
There you have it - a powerful, globally distributed thumbnail system that's surprisingly easy to set up. Give it a try and watch those load times plummet!
